Rain Bird Mpr Series Side Strip Spray Nozzle
SKU:
121628
UPC:
077985471286
$2.79
Trusted for decades, Rain Bird MPR Nozzles are installed by more contractors than all other brands combined. MPR Nozzles simplify the design process by allowing sprinklers with various arcs and radii to be mixed on the same circuit while maintaining even water distribution rates. They fit all Rain Bird spray heads and shrub adapters.
Features
- Rain Bird 15SSTC1 Side Strip Pattern Matched Precipitation Rate Spray Nozzle, Adjustable 3' X 20' to 4' X 30' Spray Distance
- Trusted for decades, Rain Bird MPR Nozzles feature Matched Precipitation Rate watering distribution technology
- Nozzles with varying arcs and radii can be mixed on the same zone regardless of spray adjustment and still maintain even water distribution rates
- MPR nozzles are designed to provide uniform coverage, ensuring that your lawn is green throughout
- Stainless steel adjustment screw adjusts spray distance from 3' X 20' to 4' X 30'
- Nozzle sprays a side strip pattern at a 30° trajectory and fits all Rain Bird pop-up sprinklers and shrub adapters
- Mesh filter screen protects from clogging and maintains precise radius adjustment. Non-corrosive plastic and stainless steel construction for long life. Rain Bird “The Intelligent Use of Water"
Sort Quicker, Install Faster, Check Easier!
Rain Bird MPR Spray nozzles are color-coded on the top to enhance your productivity.
- Quickly identify radius and arc with Top Color-coded nozzles
Now it's easier to sort, easier to organize, and easier to install with Top Color-coded nozzles.
Specifications
- Nozzle Radius: 9'
- Nozzle Pattern: Specialty
- Nozzle Type: Fixed spray
- Spacing: 3' to 20' (0.9 To 4.6m)
- Pressure: 15 to 30 psi (1,0 to 2,1 bar)
- Optimum Pressure: 30 psi (2,1 bar)
Trusted for decades, Rain Bird MPR Nozzles are installed by more contractors than all other brands combined. MPR Nozzles simplify the design process by allowing sprinklers with various arcs and radii to be mixed on the same circuit while maintaining even water distribution rates. They fit all Rain Bird spray heads and shrub adapters.
Features
- Rain Bird 15SSTC1 Side Strip Pattern Matched Precipitation Rate Spray Nozzle, Adjustable 3' X 20' to 4' X 30' Spray Distance
- Trusted for decades, Rain Bird MPR Nozzles feature Matched Precipitation Rate watering distribution technology
- Nozzles with varying arcs and radii can be mixed on the same zone regardless of spray adjustment and still maintain even water distribution rates
- MPR nozzles are designed to provide uniform coverage, ensuring that your lawn is green throughout
- Stainless steel adjustment screw adjusts spray distance from 3' X 20' to 4' X 30'
- Nozzle sprays a side strip pattern at a 30° trajectory and fits all Rain Bird pop-up sprinklers and shrub adapters
- Mesh filter screen protects from clogging and maintains precise radius adjustment. Non-corrosive plastic and stainless steel construction for long life. Rain Bird “The Intelligent Use of Water"
Sort Quicker, Install Faster, Check Easier!
Rain Bird MPR Spray nozzles are color-coded on the top to enhance your productivity.
- Quickly identify radius and arc with Top Color-coded nozzles
Now it's easier to sort, easier to organize, and easier to install with Top Color-coded nozzles.
Specifications
- Nozzle Radius: 9'
- Nozzle Pattern: Specialty
- Nozzle Type: Fixed spray
- Spacing: 3' to 20' (0.9 To 4.6m)
- Pressure: 15 to 30 psi (1,0 to 2,1 bar)
- Optimum Pressure: 30 psi (2,1 bar)
